1. It has two intelligent modules: photosensitive and remote wireless communication intelligent management and control,widely used in oil extraction, oil refining, chemical industry, military and other dangerous environment and offshore oil platforms, oil tankers and other places for common lighting and working lighting;
2. Suitable for lighting energy saving renovation project and the replacement of difficult places;
3. Suitable for explosive gas environment zone 1, zone 2;
4. Explosive atmosphere: class ⅡA,ⅡB,ⅡC;
5. Suitable for combustible dust environment in the area 22, 21;
6. Suitable for high protection requirements, damp places;
7. Suitable for environments from -50℃ to +50 .
1. Aluminum alloy die-casting shell, electrostatic plastic spraying on the surface, beautiful appearance.
2. Intelligent explosion-proof LED lamps can realize automatic operation of turning on, turning off and dimming according to the setting of intelligent lighting system without manual controle.
3. Intelligent explosion-proof LED lamps can be attached with human body sensing function, which can light up the intelligent explosion- proof lamps in the area when sensing pedestrians.
4. The distance between intelligent lamps can realize effective communication (ZigBee outdoor) of no less than 300m, and can carry out dynamic self-organization, self configuration, self maintenance, ensuring stable network communication and other outstanding characteristics.
5. With intelligent dimming function, it can sense that after the human body moves within the monitored range, the lamps will switch according to the set brightness.
6. Pure flameproof three chamber composite structure, together with external intelligent sensor, forms an explosion-proof intelligent LED lamp, which is suitable for explosive gas and combustible dust environment, with excellent explosion-proof performance and photometric performance.
7. Stainless steel exposed fasteners with high corrosion resistance.
8. Tempered glass transparent cover, atomization anti glare design, can withstand high-energy impact, anti thermal fusion, and the light transmittance is as high as 90%.
9. Advanced driving power technology, wide voltage input, constant current, open circuit protection, short circuit protection, surge protection and other functions.
10.Multiple international brand LED modules, secondary light distribution system designed by professional optical software, uniform and soft light, light efficiency ≥120lm / W, high color rendering, long service life, green and environmental protection.
11.The open heat dissipation air duct can effectively dissipate the heat of the light source and power supply to ensure the service life of the lamps.
12.The lamp adopts special structural design, and the surface is sprayed with outdoor plastic powder. The anti-corrosion grade reaches (damp hot zone th) WF2. The lamp can work continuously and reliably in all seasons. The whole set of lamps can be fully applicable to the extreme climate conditions of "marine climate environment in tropical and subtropical monsoon climate area".
13.All connections of the lamp shell are equipped with silicone rubber sealing device, and the protection grade reaches IP66, which can effectively prevent water spraying, rain and dust from entering.
14.The flameproof joint surface of the lamp shell is processed by high-precision CNC machine tool with high precision and smooth surface. All flameproof surfaces are coated with 204-1 replacement antirust oil to effectively improve the anti-corrosion performance of the flameproof surface.
15.Special internal and external grounding terminals are set on the lamp shell, and special grounding symbols are marked. All non-conductive metal parts of the lamp are connected into one, and connected with the grounding terminal with special grounding conductor. The grounding conductor adopts yellow and green special conductor.
16.The surfaces of lamps, poles and installation accessories are sprayed with outdoor plastic powder. Through high and low temperature, damp heat alternation and outdoor strong corrosion protection test, the anti-corrosion grade reaches (damp heat belt type th) outdoor strong corrosion protection WF2, which has the ability of outdoor wet heat strong corrosion protection.
17.It can provide light distribution curves of various power of lamps and provide lighting simulation design scheme for the buyer.
18.The lamp adopts multiple distributed LED light sources, the LED chip adopts "Kerui" or "OSRAM" brand, and adopts lens light distribution. The light is soft and uniform, the light efficiency of the light source is greater than 120lm / W, and the color rendering RA > 80; Long service life, low light attenuation, and the theoretical service life is more than 60000 hours.
19. The lamps adopt wide voltage input (AC90V ~ 280v) and are equipped with constant power output and constant current driving power supply, with open circuit, short circuit, thermal protection, lightning protection, surge protection and other protection functions; The lamp can be started instantly, the luminous flux output is constant, and the luminous flux maintenance rate of 50000 hours is greater than 80%.
