MBG series
Explosion-proof isolating sealed connector
1. It is widely used in flammable and explosive gas environment, such as oil extraction, oil refining, chemical industry, offshore oil platform, oil tanker and other flammable dusty places such as military industry, port, grain storage and metal processing.
2. Suitable for explosive gas environment zone 1, zone 2;
3. Explosive atmosphere: class ⅡA,ⅡB, ⅡC;
4. Suitable for combustible dust environment in the area 22, 21;
5. Suitable for high protection requirements, damp places.
Model Implication
Features
1. Enclosure is cast with aluminium alloy, surface is sprayed with plastic, fine outline;
2. The structures are various, which are convenient for installation;
Main Technical Parameters
Order Note
1. Accord with the model implication's rules to select regularly, and Ex-mark should be added behind model implication. The template is as following: code for product model implication+Ex-mark.For example, we need explosion-proof isolating sealed connector, whose nominal is G15 , and vertical type . The model implication is “MBG-G15L+Exd II Gb+20”.
2. If there are some special requirements, it should be pointed as ordering.
