8059 series
Explosion & corrosion-proof AC contactor
1. Hazardous: division 1&2;
2. Explosive atmosphere: class Ⅱ A, Ⅱ B, Ⅱ C;
3. Serious erosive gas environment;
4. This product can not use alone it must be used together with other explosion-proof enclosure.
Model Implication
Features
1. The outer casing is made of glass fiber unsaturated polyester resin with high strength, corrosion resistance and thermal stability;
2. Built-in AC contactor or mechanical interlocking reversible AC contactor, can directly start and stop the motor directly (near control) or remote control, reversible AC contactor can control the forward and reverse operation of the motor;
3. The housing is provided with a main terminal contact and an auxiliary contact.
Main Technical Parameters
